The TTConnect 616 Configurable Switch is designed for application development and support of Ethernet in-vehicle network architectures.

The versatile switch includes 6 x 100BASE-T1 BroadRReach® physical layer interfaces that enable 100 Mbit/s full-duplex communication over unshielded twisted single pair (UTSP) cabling in addition to one 100BASE-TX port for diagnostics and flashing.

TTConnect 616 was specifically developed for vehicles and machines used in rugged operating environments and atmore
Unit of Measure

Specifications

Model Code Description

 TTConnect 616-SW-0-0-00-00-000

N/A

  • Infineon AURIX 32-bit super-scalar CPUs with 3 cores at 300 MHz
  • Up to 8 MB of Program Flash
  • Up to 768 kB Data Flash usable for EEPROM emulation
  • Up to 728 kB RAM
  • 2 x SJA1105T - 5 port Ethernet Switch Chip

Weight

 0.73 lb

Operating Temperature [Min]

 -40 ºC

Operating Temperature [Max]

 85 ºC

Length

 147 mm

Height

 38 mm

Width

 92 mm

Minimum Connector Release Clearance Length

 208 mm

Minimum Connector Release Clearance Width

 92 mm

Minimum Connector Release Clearance Height

 38 mm

Supply Voltage

 8 to 16 V

Maximum Peak Voltage

 16 V

Maximum Standby Current

 ≤ 400 mA

Maximum Current

 ≤ 5 A A

CE - Mark

 2014/30/EU

E - Mark

 ECE-R10 Rev. 5

EMV

 ISO 7637-2, EN 55025, ISO 11452-1, -2, -4, -5

Electrostatic Discharge (ESD)

 ISO 10605

Load Dump

 ISO 16750-2 Load Dump +35 V, 2 Ohm, 400 ms

Ingress Protection (IP) Class

 EN 60529 IP67, ISO 20653 IP 6K9K

Climatic

 EN 60068-2-14 Na, Nb, 60068-2-78, -30 Db, -2, -1, EN 50581

Vibration, Shock, Bump

 IEC 60068-2-64, -27

Interface

Interface
  • 6 x 100BASE-T1 BroadR-Reach® 100 Mbit/full-duplex
  • 1 x 100BASE-TX Ethernet for diagnostics and flashing

Configurability

Configurability
  • VLANs
  • Master/Slave ports
  • Simple configuration of switch using templates
  • Additional parameter configuration can be supplied

Note

N/A All I/Os and interfaces are protected against short circuits to GND and BAT+ and can be configured by software. Details about the standards can be found in the user manual.
