Part Number |
Model Code Description |
Mechanical Connection Type |
Output Signal |
Electrical Connection |
Input Measuring Range |
|---|---|---|---|---|---|
| 907319 | Model Code Description N/A HDA 4444-A-060-000 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 4 to 20 mA | Electrical Connection N/A Male, 4 Pole Binder Series 714 M18 (Mating Connector Not Supplied) | Input Measuring Range N/A 60 bar |
| 907291 | Model Code Description N/A HDA 4444-A-100-000 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 4 to 20 mA | Electrical Connection N/A Male, 4 Pole Binder Series 714 M18 (Mating Connector Not Supplied) | Input Measuring Range N/A 100 bar |
| 907363 | Model Code Description N/A HDA 4444-A-250-000 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 4 to 20 mA | Electrical Connection N/A Male, 4 Pole Binder Series 714 M18 (Mating Connector Not Supplied) | Input Measuring Range N/A 250 bar |
| 906816 | Model Code Description N/A HDA 4444-A-400-000 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 4 to 20 mA | Electrical Connection N/A Male, 4 Pole Binder Series 714 M18 (Mating Connector Not Supplied) | Input Measuring Range N/A 400 bar |
| 907298 | Model Code Description N/A HDA 4444-A-600-000 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 4 to 20 mA | Electrical Connection N/A Male, 4 Pole Binder Series 714 M18 (Mating Connector Not Supplied) | Input Measuring Range N/A 600 bar |
| 907294 | Model Code Description N/A HDA 4444-B-060-000 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 0 to 10 V | Electrical Connection N/A Male, 4 Pole Binder Series 714 M18 (Mating Connector Not Supplied) | Input Measuring Range N/A 60 bar |
| 907297 | Model Code Description N/A HDA 4444-B-400-000 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 0 to 10 V | Electrical Connection N/A Male, 4 Pole Binder Series 714 M18 (Mating Connector Not Supplied) | Input Measuring Range N/A 400 bar |
| 909046 | Model Code Description N/A HDA 4444-B-400-031(350bar) | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 0 to 10 V | Electrical Connection N/A Male, 4 Pole Binder Series 714 M18 (Mating Connector Not Supplied) | Input Measuring Range N/A 350 bar |
| 907171 | Model Code Description N/A HDA 4445-A-016-000 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 4 to 20 mA | Electrical Connection N/A Male, 3 Pole + PE, EN175301-803 (Mating Connector Supplied) | Input Measuring Range N/A 16 bar |
| 925589 | Model Code Description N/A HDA 4445-A-016-031 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 4 to 20 mA | Electrical Connection N/A Male, 3 Pole + PE, EN175301-803 (Mating Connector Supplied) | Input Measuring Range N/A 16 bar |
| 907024 | Model Code Description N/A HDA 4445-A-060-000 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 4 to 20 mA | Electrical Connection N/A Male, 3 Pole + PE, EN175301-803 (Mating Connector Supplied) | Input Measuring Range N/A 60 bar |
| 907088 | Model Code Description N/A HDA 4445-A-100-000 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 4 to 20 mA | Electrical Connection N/A Male, 3 Pole + PE, EN175301-803 (Mating Connector Supplied) | Input Measuring Range N/A 100 bar |
| 909759 | Model Code Description N/A HDA 4445-A-160-000 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 4 to 20 mA | Electrical Connection N/A Male, 3 Pole + PE, EN175301-803 (Mating Connector Supplied) | Input Measuring Range N/A 160 bar |
| 906995 | Model Code Description N/A HDA 4445-A-250-000 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 4 to 20 mA | Electrical Connection N/A Male, 3 Pole + PE, EN175301-803 (Mating Connector Supplied) | Input Measuring Range N/A 250 bar |
| 906209 | Model Code Description N/A HDA 4445-A-400-000 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 4 to 20 mA | Electrical Connection N/A Male, 3 Pole + PE, EN175301-803 (Mating Connector Supplied) | Input Measuring Range N/A 400 bar |
| 909282 | Model Code Description N/A HDA 4445-A-400-185 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 4 to 20 mA | Electrical Connection N/A Male, 3 Pole + PE, EN175301-803 (Mating Connector Supplied) | Input Measuring Range N/A 400 bar |
| 909755 | Model Code Description N/A HDA 4445-A-400-188 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 4 to 20 mA | Electrical Connection N/A Male, 3 Pole + PE, EN175301-803 (Mating Connector Supplied) | Input Measuring Range N/A 400 bar |
| 907292 | Model Code Description N/A HDA 4445-A-600-000 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 4 to 20 mA | Electrical Connection N/A Male, 3 Pole + PE, EN175301-803 (Mating Connector Supplied) | Input Measuring Range N/A 600 bar |
| 907299 | Model Code Description N/A HDA 4445-B-016-000 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 0 to 10 V | Electrical Connection N/A Male, 3 Pole + PE, EN175301-803 (Mating Connector Supplied) | Input Measuring Range N/A 16 bar |
| 906449 | Model Code Description N/A HDA 4445-B-040-004 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 0 to 10 V | Electrical Connection N/A Male, 3 Pole + PE, EN175301-803 (Mating Connector Supplied) | Input Measuring Range N/A 40 bar |
| 906502 | Model Code Description N/A HDA 4445-B-060-000 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 0 to 10 V | Electrical Connection N/A Male, 3 Pole + PE, EN175301-803 (Mating Connector Supplied) | Input Measuring Range N/A 60 bar |
| 907006 | Model Code Description N/A HDA 4445-B-100-000 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 0 to 10 V | Electrical Connection N/A Male, 3 Pole + PE, EN175301-803 (Mating Connector Supplied) | Input Measuring Range N/A 100 bar |
| 906838 | Model Code Description N/A HDA 4445-B-250-000 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 0 to 10 V | Electrical Connection N/A Male, 3 Pole + PE, EN175301-803 (Mating Connector Supplied) | Input Measuring Range N/A 250 bar |
| 922394 | Model Code Description N/A HDA 4445-B-250-000+PP | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 0 to 10 V | Electrical Connection N/A Male, 3 Pole + PE, EN175301-803 (Mating Connector Supplied) | Input Measuring Range N/A 250 bar |
| 906450 | Model Code Description N/A HDA 4445-B-250-004 | Mechanical Connection Type N/A G1/4 A ISO 1179-2, Male | Output Signal N/A 0 to 10 V | Electrical Connection N/A Male, 3 Pole + PE, EN175301-803 (Mating Connector Supplied) | Input Measuring Range N/A 250 bar |
