909617
Model Code Description
N/A ETS 3226-2-018-000
Measuring Range
N/A -25 to 100 ºC -13 to 212 ºF
Input Probe Length
N/A 0.71 in 18 mm
Input Mechanical Connection Type
N/A G1/2 A DIN 3852, Male
Switch Outputs Type
N/A PNP Transistor Switching Output
Electrical Connection
N/A Male M12x1, 4 Pole
909618
Model Code Description
N/A ETS 3226-2-100-000
Measuring Range
N/A -25 to 100 ºC -13 to 212 ºF
Input Probe Length
N/A 3.93 in 100 mm
Input Mechanical Connection Type
N/A G1/2 A DIN 3852, Male
Switch Outputs Type
N/A PNP Transistor Switching Output
Electrical Connection
N/A Male M12x1, 4 Pole
909619
Model Code Description
N/A ETS 3226-2-250-000
Measuring Range
N/A -25 to 100 ºC -13 to 212 ºF
Input Probe Length
N/A 9.84 in 250 mm
Input Mechanical Connection Type
N/A G1/2 A DIN 3852, Male
Switch Outputs Type
N/A PNP Transistor Switching Output
Electrical Connection
N/A Male M12x1, 4 Pole
909620
Model Code Description
N/A ETS 3226-2-350-000
Measuring Range
N/A -25 to 100 ºC -13 to 212 ºF
Input Probe Length
N/A 13.77 in 350 mm
Input Mechanical Connection Type
N/A G1/2 A DIN 3852, Male
Switch Outputs Type
N/A PNP Transistor Switching Output
Electrical Connection
N/A Male M12x1, 4 Pole
909624
Model Code Description
N/A ETS 3226-3-018-000
Measuring Range
N/A -25 to 100 ºC -13 to 212 ºF
Input Probe Length
N/A 0.71 in 18 mm
Input Mechanical Connection Type
N/A G1/2 A DIN 3852, Male
Switch Outputs Type
N/A PNP Transistor Switching Output
Electrical Connection
N/A Male M12x1, 4 Pole
909525
Model Code Description
N/A ETS 3226-3-100-000
Measuring Range
N/A -25 to 100 ºC -13 to 212 ºF
Input Probe Length
N/A 3.93 in 100 mm
Input Mechanical Connection Type
N/A G1/2 A DIN 3852, Male
Switch Outputs Type
N/A PNP Transistor Switching Output
Electrical Connection
N/A Male M12x1, 4 Pole
922062
Model Code Description
N/A ETS 3226-3-100-400
Measuring Range
N/A -25 to 100 ºC -13 to 212 ºF
Input Probe Length
N/A 3.93 in 100 mm
Input Mechanical Connection Type
N/A G1/2 A DIN 3852, Male
Switch Outputs Type
N/A PNP Transistor Switching Output
Electrical Connection
N/A Male M12x1, 4 Pole
909625
Model Code Description
N/A ETS 3226-3-250-000
Measuring Range
N/A -25 to 100 ºC -13 to 212 ºF
Input Probe Length
N/A 9.84 in 250 mm
Input Mechanical Connection Type
N/A G1/2 A DIN 3852, Male
Switch Outputs Type
N/A PNP Transistor Switching Output
Electrical Connection
N/A Male M12x1, 4 Pole
909626
Model Code Description
N/A ETS 3226-3-350-000
Measuring Range
N/A -25 to 100 ºC -13 to 212 ºF
Input Probe Length
N/A 13.77 in 350 mm
Input Mechanical Connection Type
N/A G1/2 A DIN 3852, Male
Switch Outputs Type
N/A PNP Transistor Switching Output
Electrical Connection
N/A Male M12x1, 4 Pole
909095
Model Code Description
N/A ETS 3228-5-018-000
Measuring Range
N/A -25 to 100 ºC -13 to 212 ºF
Input Probe Length
N/A 0.71 in 18 mm
Input Mechanical Connection Type
N/A G1/2 A DIN 3852, Male
Switch Outputs Type
N/A PNP Transistor Switching Output
Electrical Connection
N/A Male M12x1, 5 Pole
909621
Model Code Description
N/A ETS 3228-5-100-000
Measuring Range
N/A -25 to 100 ºC -13 to 212 ºF
Input Probe Length
N/A 3.93 in 100 mm
Input Mechanical Connection Type
N/A G1/2 A DIN 3852, Male
Switch Outputs Type
N/A PNP Transistor Switching Output
Electrical Connection
N/A Male M12x1, 5 Pole
924917
Model Code Description
N/A ETS 3228-5-100-400
Measuring Range
N/A -25 to 100 ºC -13 to 212 ºF
Input Probe Length
N/A 3.93 in 100 mm
Input Mechanical Connection Type
N/A G1/2 A DIN 3852, Male
Switch Outputs Type
N/A PNP Transistor Switching Output
Electrical Connection
N/A Male M12x1, 5 Pole
909622
Model Code Description
N/A ETS 3228-5-250-000
Measuring Range
N/A -25 to 100 ºC -13 to 212 ºF
Input Probe Length
N/A 9.84 in 250 mm
Input Mechanical Connection Type
N/A G1/2 A DIN 3852, Male
Switch Outputs Type
N/A PNP Transistor Switching Output
Electrical Connection
N/A Male M12x1, 5 Pole
909623
Model Code Description
N/A ETS 3228-5-350-000
Measuring Range
N/A -25 to 100 ºC -13 to 212 ºF
Input Probe Length
N/A 13.77 in 350 mm
Input Mechanical Connection Type
N/A G1/2 A DIN 3852, Male
Switch Outputs Type
N/A PNP Transistor Switching Output
Electrical Connection
N/A Male M12x1, 5 Pole
