Flow (gpm)

  • 250

Flow (L/min)

  • 950

Filter Rating (µm)

  • 3
  • 5
  • 10
  • 20
  • 25

Bypass Valve

Seal Material

  • Fluorocarbon elastomer (FKM)
  • Nitrile rubber (NBR) (standard)

Material

  • Betamicron®
  • Housing only

Indication Type

  • A = No indicator, plugged port
  • B = Pop-up indicator (auto reset)
  • B = Visual Pop-Up (Auto Reset)
  • BM = Visual pop-up with manual reset
  • C = Electrical Switch
  • D = Electric Switch and Visual (Light - 24 VDC, 110 VAC)
  • LZ = Electric Pressure Switch/Visual Pop-Up Button with 75% and 100% Switching Contact
  • No Indicator

End Type

End Size

End Size (in)

Part Number

Model Code Description

Flow

Operating Pressure [Max]

Filter Rating

Bypass Valve

Seal Material

Core Products

N/A DF1500TLLXXA2.0/-B6 N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A N/A B6 N/A Nitrile rubber (NBR) (standard)
N/A DFF1500TLXXA2.0/-V N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A N/A Non-Bypass N/A Fluorocarbon elastomer (FKM)
N/A DFF1500TLLXXA2.0 N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A N/A Non-Bypass N/A Nitrile rubber (NBR) (standard)
N/A DFFBH/HC1500TL5LZ2.0 N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A 5 µm N/A Non-Bypass N/A Nitrile rubber (NBR) (standard)
N/A DFBN/HC1500TLL10BM2.0/B6 N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A 10 µm N/A B6 N/A Nitrile rubber (NBR) (standard)
N/A DF1500TLLXXBM2.0/-B6 N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A N/A B6 N/A Nitrile rubber (NBR) (standard)
N/A DFFBH/HC1500TLL20C3.0 N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A 20 µm N/A Non-Bypass N/A Nitrile rubber (NBR) (standard)
N/A DFBH/HC1500TL10A2.0/V N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A 10 µm N/A Non-Bypass N/A Fluorocarbon elastomer (FKM)
N/A DFBN/HC1500TL10A2.0/V-B6 N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A 10 µm N/A B6 N/A Fluorocarbon elastomer (FKM)
N/A DFBH/HC1500TL10B2.0/V N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A 10 µm N/A Non-Bypass N/A Fluorocarbon elastomer (FKM)
N/A DFBN/HC1500TLL10D3.0/B6-L110 N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A 10 µm N/A B6 N/A Nitrile rubber (NBR) (standard)
N/A DFFBH/HC1500TL10D2.0/-L24 N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A 10 µm N/A Non-Bypass N/A Nitrile rubber (NBR) (standard)
N/A DFBH/HC1500TL5B3.0/V-B3 N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A 5 µm N/A B3 N/A Fluorocarbon elastomer (FKM)
N/A DFFBH/HC1500TL5D2.0/L24 N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A 5 µm N/A Non-Bypass N/A Nitrile rubber (NBR) (standard)
N/A DFBN/HC1500TL20BM2.0/B6 N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A 20 µm N/A B6 N/A Nitrile rubber (NBR) (standard)
N/A DFBN/HC1500TL3C2.0/B6 N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A 3 µm N/A B6 N/A Nitrile rubber (NBR) (standard)
N/A DFW/HC1500TL25A2.0/V N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A 25 µm N/A Non-Bypass N/A Fluorocarbon elastomer (FKM)
N/A DFBN/HC1500TL10B2.0/B6-W N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A 10 µm N/A B6 N/A Nitrile rubber (NBR) (standard)
N/A DFBN/HC1500TL3BM2.0/B6 N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A 3 µm N/A B6 N/A Nitrile rubber (NBR) (standard)
N/A DFFBH/HC1500TL10A3.0 N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A 10 µm N/A Non-Bypass N/A Nitrile rubber (NBR) (standard)
N/A DFFBH/HC1500TL10A2.0 N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A 10 µm N/A Non-Bypass N/A Nitrile rubber (NBR) (standard)
N/A DFFBH/HC1500TL20B-BM2.0 N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A 20 µm N/A Non-Bypass N/A Nitrile rubber (NBR) (standard)
N/A DFFBH/HC1500TLL10BM2.0 N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A 10 µm N/A Non-Bypass N/A Nitrile rubber (NBR) (standard)
N/A DF 1500 SET XX W 3.0 N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A N/A Non-Bypass N/A Nitrile rubber (NBR) (standard)
N/A DFFBH/HC1500TLL10A2.0 N/A 250 gpm950 L/min N/A 420 bar6090 psi N/A 10 µm N/A Non-Bypass N/A Nitrile rubber (NBR) (standard)
