  • HE_HDA 4748-H_sw.png
To extend the number of sensors on the HMG 4000, the special CAN-based HCSI sensors were developed. The HCSI sensors, easily identified by their red type label, are automatically recognized along with all their characteristics by the HMG 4000. Up to 28 HCSI sensors can be connected to the HMG 4000 via the Y-distributor (available as an accessory) to set up an HMG-internal bus system.
1 - 8 of 8 | Results Per Page | View | Unit of Measure
1
Request a Quote Compare Items

Part Number

Model Code Description

Mechanical Connection Size

Output Signal

Electrical Connection

Measuring Range

Core Products

N/A HDA 4748-HC-0009-000(- 1 ... 9 BAR) N/A G 1/4 A, Male N/A HCSI (HYDAC CAN Sensor Interface)

Automatic sensor recognition 		N/A Male M12 x 1, 5 Pole N/A -1 to 9 bar
N/A HDA 4748-HC-0016-000 N/A G 1/4 A, Male N/A HCSI (HYDAC CAN Sensor Interface)

Automatic sensor recognition 		N/A Male M12 x 1, 5 Pole N/A 0 to 16 bar
N/A HDA 4748-HC-0060-000 N/A G 1/4 A, Male N/A HCSI (HYDAC CAN Sensor Interface)

Automatic sensor recognition 		N/A Male M12 x 1, 5 Pole N/A 0 to 60 bar
N/A HDA 4748-HC-0100-000 N/A G 1/4 A, Male N/A HCSI (HYDAC CAN Sensor Interface)

Automatic sensor recognition 		N/A Male M12 x 1, 5 Pole N/A 0 to 100 bar
N/A HDA 4748-HC-0250-000 N/A G 1/4 A, Male N/A HCSI (HYDAC CAN Sensor Interface)

Automatic sensor recognition 		N/A Male M12 x 1, 5 Pole N/A 0 to 250 bar
N/A HDA 4748-HC-0400-000 N/A G 1/4 A, Male N/A HCSI (HYDAC CAN Sensor Interface)

Automatic sensor recognition 		N/A Male M12 x 1, 5 Pole N/A 0 to 400 bar
N/A HDA 4748-HC-0600-000 N/A G 1/4 A, Male N/A HCSI (HYDAC CAN Sensor Interface)

Automatic sensor recognition 		N/A Male M12 x 1, 5 Pole N/A 0 to 600 bar
N/A HDA 4748-HC-1000-000 N/A G 1/4 A, Male N/A HCSI (HYDAC CAN Sensor Interface)

Automatic sensor recognition 		N/A Male M12 x 1, 5 Pole N/A 0 to 1000 bar
