909497
Model Code Description
N/A HDA 4745-A-0006-S00
Mechanical Connection Type
N/A G1/4 A ISO 1179-2, Male
Output Signal
N/A 4 to 20 mA
Electrical Connection
N/A Male, EN175301-803, 3 Pole + PE
Operating Pressure [Max]
N/A 6 bar
Core Products
908794
Model Code Description
N/A HDA 4745-A-0016-S00
Mechanical Connection Type
N/A G1/4 A ISO 1179-2, Male
Output Signal
N/A 4 to 20 mA
Electrical Connection
N/A Male, EN175301-803, 3 Pole + PE
Operating Pressure [Max]
N/A 16 bar
Core Products
909291
Model Code Description
N/A HDA 4745-A-0250-S00
Mechanical Connection Type
N/A G1/4 A ISO 1179-2, Male
Output Signal
N/A 4 to 20 mA
Electrical Connection
N/A Male, EN175301-803, 3 Pole + PE
Operating Pressure [Max]
N/A 250 bar
Core Products
909551
Model Code Description
N/A HDA 4745-A-060-S00
Mechanical Connection Type
N/A G1/4 A ISO 1179-2, Male
Output Signal
N/A 4 to 20 mA
Electrical Connection
N/A Male, EN175301-803, 3 Pole + PE
Operating Pressure [Max]
N/A 60 bar
Core Products
909098
Model Code Description
N/A HDA 4745-A-0600-S00
Mechanical Connection Type
N/A G1/4 A ISO 1179-2, Male
Output Signal
N/A 4 to 20 mA
Electrical Connection
N/A Male, EN175301-803, 3 Pole + PE
Operating Pressure [Max]
N/A 600 bar
Core Products
909468
Model Code Description
N/A HDA 4745-A-400-S00
Mechanical Connection Type
N/A G1/4 A ISO 1179-2, Male
Output Signal
N/A 4 to 20 mA
Electrical Connection
N/A Male, EN175301-803, 3 Pole + PE
Operating Pressure [Max]
N/A 400 bar
Core Products
921596
Model Code Description
N/A HDA 4775-A-1500-S00(PSI)
Mechanical Connection Type
N/A 9/16-18 UNF 2A (SAE 6 Male)
Output Signal
N/A 4 to 20 mA
Electrical Connection
N/A Male, EN175301-803, 3 Pole + PE
Operating Pressure [Max]
N/A 1500 psi
Core Products
921579
Model Code Description
N/A HDA 4775-A-5000-S00(PSI)
Mechanical Connection Type
N/A 9/16-18 UNF 2A (SAE 6 Male)
Output Signal
N/A 4 to 20 mA
Electrical Connection
N/A Male, EN175301-803, 3 Pole + PE
Operating Pressure [Max]
N/A 5000 psi
Core Products
2084117
Model Code Description
N/A HDA 4785-A-006-S00
Mechanical Connection Type
N/A 1/4-18 NPT Male (with Adapter)
Output Signal
N/A 4 to 20 mA
Electrical Connection
N/A Male, EN175301-803, 3 Pole + PE
Operating Pressure [Max]
N/A 6 bar
Core Products
2077502
Model Code Description
N/A HDA 4785-A-016-S00
Mechanical Connection Type
N/A 1/4-18 NPT Male (with Adapter)
Output Signal
N/A 4 to 20 mA
Electrical Connection
N/A Male, EN175301-803, 3 Pole + PE
Operating Pressure [Max]
N/A 16 bar
Core Products
2084730
Model Code Description
N/A HDA 4785-A-060-S00
Mechanical Connection Type
N/A 1/4-18 NPT Male (with Adapter)
Output Signal
N/A 4 to 20 mA
Electrical Connection
N/A Male, EN175301-803, 3 Pole + PE
Operating Pressure [Max]
N/A 60 bar
Core Products
